Description
This USB Type-C™ Power Dock is an accessory that works with Windows®, macOS® X and Android™ OS, featuring a USB™ Hub that offers Power Delivery charging, HDMI™ video output, memory card reader, and 2x USB™ Type-A ports. It also offers USB™ 3.1 Gen-1 SuperSpeed data link to your USB-C™ laptop for on-the-go convenience. The USB-C™ Hub with 45W power adapter has an embedded Power Delivery 2.0 charger, which can supply up to 35W PD to charge a USB-C™ PD charging device.
Features
- USB Type-C™ portable dock with built-in power supply 45W
- Supports HDMI™ output resolution 4K @ 30 Hz
- Memory card compatible
- Supports USB Type-C™ upstream charging, power delivery 2.0 (maximum 35W)
- USB™ 3.1 Gen-1 data transfer up to 5 Gbps
- 2x USB™ ports support BC1.2 (max 1.5A) in AC mode
USB Type-C™ 3.1 Powered Mini Docking station gives you the flexibility of having 5 devices in 1:
- AC Adapter
- AC USB™ Wall Charger
- USB™ 3.1 Gen1 Hub
- HDMI™ port
- USB™ to Memory Card Reader
Specifications:
|
Functions |
|
|
HDMI™ Output |
HDMI™ 1.4 Resolution: |
|
USB Type-C™ (Gen1) |
|
|
Memory Card Reader |
|
|
USB™ Type-A Port-1 & Port-2 USB™ 3.1 (Gen1) |
|
|
Input AC Power |
100/240V AC |
|
Physical Specifications |
|
|
Case Material |
ABS |
|
Color |
White |
|
Dimensions |
Main Body: |
|
Weight |
Approximately: 139g |
|
Environmental |
|
|
Storage Temperature |
-20-65°C |
|
Storage Humidity |
5-90% RH. Non-Condensing |
|
Operation Temperature |
0-35°C |
|
Operation Humidity |
20-85% RH. Non-Condensing |
System Requirements
- Available DisplayPort™ Alt Mode over USB Type-C™ port
- USB™ PD 2.0 compatible for upstream charging
